Madho Pneumatics
Image 01
Pneumatic Cylinder Actuator Valves - Series 1900
Body Cast Iron, Cast Carbon Steel
Size 15mm (1/2") to 50mm (2")
Actuator Pressed Stainless Steel
Temperature 1700
Air Pressure 6 Kg/cm2
Line Pressure 10 Kg/cm2
End Connection Flanged End
Service Steam, Water


Image 01
Pneumatic Cylinder Actuator Valves-Series 600 - 3 Way
Body Investment Casting CF8 (SS304) / CF 8M (SS316)
Size 15mm (1/2") to 50mm (2")
Actuator Pressed Stainless Steel
Temperature 1700
Air Pressure 6 Kg/cm2
Line Pressure 10 Kg/cm2
End Connection Screwed End (F), Flanged End
Service Steam, Water, Vacuum, Air, Gas, Light Oil, Coolant


Image 01
Pneumatic Cylinder Actuator Valves - Series 700
Body Cast Iron, Cast Carbon Steel
Size 15mm (1/2") to 100mm (4")
Actuator Pressed Stainless Steel, Aluminium
Temperature 1700
Air Pressure 6 Kg/cm2
Line Pressure 10 Kg/cm2
End Connection Flanged End
Service Chemicals, Steam, Water


Image 01
Pneumatic Cylinder Actuator Valves - Series 1400
Body Stainless Steel SS 304, SS 316
Size 65mm (2.5") to 200mm (8")
Actuator Aluminium
Temperature 1700
Air Pressure 6 Kg/cm2
Line Pressure 4 Kg/cm2
End Connection Flanged End
Service Chemicals, Steam, Water
